Native Instruments has announced that Traktor Pro 3.3.0 is now available, the headline feature being comprehensive iTunes/Music integration.

Other improvements include integration with Pioneer DJ’s XDJ-1000Mk2 and XDJ-700 media player plus the new DJM-V10 mixer, and Midi mapping for the Traktor Kontrol S3 controller.

This launches today and users should check for updates in the usual way in order to get the latest version. More info on Traktor over on the Native Instruments website.

Learn how to DJ properly:Get our Complete DJ Course.

Full list of changes

Here’s the complete list, as provided by the Traktor team:

ADDED Pioneer XDJ-1000MK2 Integration
Plug and play integration of the XDJ-1000MK2 including full display support, RGB waveforms and all performance features.

ADDED Pioneer XDJ-700 Integration
Plug and play integration of the XDJ-700 including full display support and all performance features.

ADDED Pioneer DJM-V10 Integration
Plug and play integration of the DJM-V10 including automatic configuration of input and output channels.

ADDED Comprehensive iTunes/Music integration
Faster and deeper iTunes/Music integration via API, with the option to revert to XML based integration for legacy use cases.

ADDED Custom Mapping (over-mapping) for S3
The factory mapping of KONTROL S3 can now be customised like the mappings of S2MK3 and S4MK3.

FIXED Headroom not applied to preview deck in external mixing mode
The headroom setting is now also applied to the preview deck in external mixing mode.

FIXED Keyboard focus is on Main UI with Preference Window open
When you open the Preference window and press Enter or ESC it now correctly closes the window.

FIXED Scratch controlled deck loses Sync when loading new track
Loading new tracks into a scratch controlled playing and synched deck will continue to play in perfect sync.

FIXED S4MK3 Tempo Fader neutral zone too wide
The neutral zone around the center-point of the S4MK3 Tempo Fader is now as narrow as it was before.

FIXED Decks lose sync by moving the tempo fader on S4MK3
Synched decks are now locked against tempo changes via hardware, such as the S4MK3.

FIXED Some M4A files can’t be played on Windows
All M4A files containing any kind of special characters in the file name can now be loaded and played on Windows.

FIXED Some iTunes playlists are not shown
All iTunes playlists are shown, including those which duplicate names of folders.

FIXED Crash when clicking on Music folder (Windows)
Traktor on Windows no longer crashes under certain circumstances when clicking on the Music folder.

FIXED TagLib related crash on Windows
With this fix we no longer observe TagLib related crashes on Windows and macOS.

FIXED Beat Phase output controller range incorrect
The Beat Phase output Controller Range now correctly shows [-0.5. .+0.5].

FIXED STEMS with inconsistent stem lengths not usable
STEM files will now analyse and play fine even with slightly different length of the individual stems.

FIXED Certain Tracks cannot be analysed
Files will no longer fail to analyse with the error: “Cannot execute BPM-detection due to missing transients! Please analyse first”.

FIXED Star Rating not imported from iTunes/Music on first import
The iTunes/Music star rating is now instantly imported into Traktor on first import/play of the file.

FIXED Focused and unfocused Deck A letter not aligned
The Deck A letter of the focused and unfocused deck are now perfectly aligned.

Sara Simms is here to take you beyond the techniques in her recent article on creating MIDI mappings in Traktor Pro. Learn how to create 2 advanced mappings in NIs Traktor Pro.

In one of my recent articles, I demonstrated how to create a simple MIDI mapping in Traktor Pro. If you're ready to advance your mapping skills, let's learn to create two advanced mappings in Traktor.


Load and Sync

The first mapping that we'll create allows you to load and sync a track at the same time, and trigger both functions from a single button. This is a highly useful mapping if you're a digital DJ, who frequently uses the Sync function in your sets.

Start by opening Traktor Pro, and connect your controller to the computer.

Then, go to Traktor > Preferences and navigate to the Controller Manager Section.

In the Device Setup section, you can either choose to modify the mapping for an existing device, or create a new MIDI mapping by clicking:

Add (located under the Device) then Generic MIDI.


For demonstration purposes, I'll modifying the mapping for my Traktor Kontrol X1. In the Assignment Table Section, scroll down to Load Selected (Deck Common – Deck A) and click to highlight it. Alternatively, you could delete this original function in the Assignment Table, (by highlighting, and deleting it) and add a new one by clicking:

Add In, Deck Common, and scroll down to select Load Selected.


In the Device Mappings Section, click the Learn button (it will turn yellow when clicked), and press down on the button on your controller that you would like to map. I've chosen to map the left Load button to this function. Alternatively, you can also select the button by mouse clicking the box directly to the right of Learn.

After you are finished, click again on the yellow Learn button to deselect it.


In the Mapping Details section, select the following settings:

  • Type of Controller: Button
  • Interaction Mode: Trigger
  • Assignment: Deck A


(Note: You may use another Deck; however you will have to set the next mapping to same deck)


In the Assignment table, find the Sync On function and highlight it, or click Add In, Deck Common and scroll down and click on Sync On.

Traktor


In the Device Mappings Section, click the Learn button (it will turn yellow when clicked), and press down on the button on your controller that you would like to map. Choose the same button that you selected for the Load function. As you can see, I've mapped the same left Load button. Remember, you can also choose to select the button by mouse-clicking on the box to the right of Learn.

In the Mapping Details section, select the following settings:

  • Type of Controller: Button
  • Interaction Mode: Hold
  • Assignment: Deck A

(Note: Make sure whichever Deck you choose is set to the same deck as the Load Selected function)


Lastly, in the Button Options section, click to the left of Invert to create a check mark in the box.

By clicking Invert, we have reversed when the Sync On feature is activated. Instead of Sync On being applied when the Load button is pressed down, Sync On is activated when the button is released.


Here's the way we have set up our mapping to work:

When we select a track and press down on the the Load button, the track is loaded up into Deck A. When we released the Load button, Sync On is activated. These two commands appear to happen simultaneously, and Sync On is never deactivated by loading tracks.

Test out your new mapping by clicking Close in the bottom of the Preferences window, and load up a track by clicking the Load button on your controller (or the button you have selected for the mapping). Your tracks should now Load and Sync at the same time!

To save your mapping, you can create a new .tsi file. Open the the Traktor Preferences, and click Export (in the lower left hand corner).

Make sure to leave following boxes are checked: Keyboard Mappings, Controller Mappings, and GUI Layout. You may wish to leave Effect Settings and Other Preferences and Settings Checked as well.


Save your .tsi file in a safe location, and close the Preferences window.

Traktor Pro 2 Windows 10


Single FX Mapping

The second mapping that we're going to create allows you to control your dry/wet FX Adjust, and select your FX using the same endless encoder.

Start by navigating to your Traktor Preferences, by clicking Traktor, then Preferences.

In the Effects Section, under the FX Panel Mode, set FX 1 to Single.


Navigate to the Controller Manager section, and in the Device Setup, choose your device or create a new one by clicking Add, then Generic MIDI.

We're going to be creating a Modifier, which allows you to map two or more functions to the same button.

Underneath the Assignment Table, click Add In, Modifier, then select Modifier #1.


In the Device Mappings section, click the Learn button so it turns yellow, and then select a pushable encoder button to assign the modifier to. Press down on the button on your controller, or mouse click in the box to the right of the Learn button. I have chosen to use left Load button.

In the Mapping Details section, select the following settings:

  • Type of Controller: Button
  • Interaction Mode: Hold
  • Assignment: Global


In the Button Options section, set the value to 1.

April 14, 2018 (6,011). Trap soul vst zip download. September 21, 2018 (6,195).


By setting the value to 1, this basically means when you hold down the button, Modifier #1 is turned on. When you are not pressing the button, the value returns to 0.

In the Assignment table, click Add In, F/X Unit and scroll down to select Dry/Wet Adjust.

In the Device Mapping section, click Learn and turn an endless encoder on your controller (or mouse click to select one). When you are finished, click the Learn button again to deselect it.

In the Mapping Details section, we now have to apply the Modifier.

In the Modifier Conditions, set the Modifier to M1, and the Value to 0.

In the Mapping Details section, select the following settings:

  • Type of Controller: Encoder
  • Interaction Mode: Relative
  • Assignment: FX Unit 1


In the Assignment table, click Add In, F/X Unit and scroll down to select Effect One Selector.

In the Device Mapping section, click Learn and turn the same endless encoder on your controller that you assigned to the Dry/Wet Adjust (or, mouse click to select one). When you are finished, click the Learn button again to deselect it.

In the Mapping Details section, under the Modifier Conditions, set your commands as follows:

  • Modifier: M1
  • Value: 1
  • Type of Controller: Encoder
  • Interaction Mode: Relative
  • Assignment: FX Unit 1


Traktor Pro 2 Mac

Close the Preferences, and check to see if your new mapping works by turning the encoder you assigned. If you have successfully created your mapping correctly, you should be able to scroll through your D/W adjust when you turn the encoder, and scroll through your Traktor effects when you press and turn the encoder.

Traktor Pro 2 Factory Mapping Download

Export your mapping, by opening up the Preferences, clicking Export, and saving your .tsi file.

Congratulations on learning two new mappings! I hope you enjoy using them when you DJ.
